Your chosen product may vary from the image shown depending on the safe and fittings you have selected.

Fire protection
120
Minutes
HE 10-07 HARTMANN ECONY FIREPROOF, 2-leaf
HE 10
HE 10
HE 10

HE 10-07 HARTMANN ECONY FIREPROOF, 2-leaf

Burglar- and fire-proof safe


Overall dimensions: 1800 × 1350 × 560 mm
Folder: 56
Security level classification: Security level B and S 2
acc. to EN 14450
Insurance cover (private use): €30,000.00
Insurance cover (commercial use): €2,500.00
Fire protection: 120 Min.


Thank you for your enquiry!

Please leave your phone number for possible questions.

Kind regards
Yours HARTMANN TRESORE-Team

Product details HE 10-07
Overall dimensions 1800 × 1350 × 560 mm
Internal dimensions 1505 × 1193 × 331 mm
Weight 995 kg
Volume 643 l
Shelves 3
Folder 56
Door hinge DIN right / DIN left
Door thickness 132 mm
Door opening angle 180 °
Door clearance dimensions (HxW) 1453 × 1103 mm
Protruding hinges/door fittings 60 mm
Anti-burglary protection standard EN 14450 und VDMA 24992 (05/95)
Security level classification Security level B and S 2
acc. to EN 14450
Certification body others
Insurance cover (private use) €30,000.00
Insurance cover (commercial use) €2,500.00
Fire protection 120 Min.
Fire safety class S 120 P
Fire protection standard EN 1047-1
Lock Double-bit lock (incl. 2 keys)
Type of lock Double bit
Lacquering/Colour RAL 7035 Light grey
Pre-drilled floor anchors Yes
Corpus thickness 72 mm
Details on the corpus Multi-walled with wrap-around fire insulation
Lock features locking mechanism on all sides
HE 10 – series
Select the version you would like
Item no Overall dimensions Weight folder
  HE 10-01 489 × 605 × 560 mm 168 kg 3
  HE 10-02 590 × 605 × 560 mm 187 kg 5
  HE 10-03 1050 × 605 × 560 mm 323 kg 10
  HE 10-07 1800 × 1350 × 560 mm 995 kg 56
